F200K

Compact housing with integrated flame sensor and switching amplifier.
Multi-step intensity adjustment.
Digital circuit design for flame evaluation.
LED status indication with 24 VDC operating voltage.
Two-channel electronic system for fail-safe operation and monitoring.
Flame intensity indication with LED bar and 4 (0) ... 20 mA analog output.
Trend indication with selectable LED bar for optimal adjustment to the flame direction.

Feature	Value
Power supply:	24 VDC ± 20 %, ≤ 4,0 W
Output contact:	≤ 42 VDC, ≥ 6 VAC/DC ≤ 0.5 A, ≥ 1.0 mA float
Frequency range:	10 ... 190 Hz (F200K1 ...) 10/20/30 ... 190 Hz (F200K2 ...)
Safety time 'operation':	t ≤ 1 s (standard) t ≤ 3 s (on request, ex factory)
Mode of operation:	Continuous operation
Protection class:	IP67NEMA 4X
Operating temperature:	-40 °C ... +75 °C (IR-1 only up to +60 °C)
Dimension:	Total length: 180 mm Diameter: 40/80 mm
Weight:	0.6 kg
Material:	Corrosion-resistant aluminum EN AW 6082 (seawater 2; atmospheric conditions 1), nickel-plated, powder-coated _{* Comparative rating from 1 (very good) to 6 (inadequate)}
Approvals:	EC Type Examination Certificate according to Directive 2014/68/EU (Pressure Equipment Directive). DIN EN 298:2012-11 EC Declaration of Conformity 2009/142/EC (Gas Appliances Directive) 2014/68/EU (Pressure Equipment Directive)

Product approved by:
